The Voltas 110 KTLX-G4 is the top-of-range 110kW three-phase on-grid string inverter in the KTLX-G4 series. With 9 MPPT trackers at 40A each, 1100V max DC input, 98.8% peak efficiency, and IP66 protection, it delivers maximum power density for utility-scale and industrial solar plants.
Key Features
- 110kW three-phase AC output (159.4A rated)
- 9 MPPT trackers (40A each)
- MPPT voltage range: 100–1080V (max 1100V DC)
- 98.8% max conversion efficiency
- Smart fan cooling
- IP66 outdoor-rated enclosure
- 10-year warranty
Technical Specifications
| Rated AC Output Power | 110,000W (110kW) |
| Max PV DC Voltage | 1100V |
| MPPT Voltage Range | 100–1080V |
| No. of MPPTs | 9 (40A each) |
| AC Output Voltage | 312–520V (Three Phase) |
| Rated AC Current | 159.4A |
| Max Efficiency | 98.8% |
| Cooling | Smart Fan |
| Protection Rating | IP66 |
| Dimensions (W×D×H) | 1000 × 654 × 300 mm |
| Weight | 85 kg |
| Warranty | 10 Years |
