The Voltas 12K-H4 is a three-phase hybrid solar inverter with 12kW AC output and 18kW PV capacity, delivering 250A battery charge current. With 2 MPPT trackers covering 200–700V, IP65 protection, and CAN/RS485 communication, it is designed for commercial hybrid solar systems.
Key Features
- 12kW three-phase AC output
- 18kW max PV input capacity
- 2 MPPT trackers (26A + 17A)
- MPPT voltage range: 200–700V (max 650V DC)
- 250A max battery charge current
- 97.90% max conversion efficiency
- CAN / RS485 communication
- IP65 protection rating
- 5-year warranty
Technical Specifications
| Rated AC Output Power | 12,000W (12kW) |
| Max PV Input Power | 18,000W |
| Max PV DC Voltage | 650V |
| MPPT Voltage Range | 200–700V |
| No. of MPPTs | 2 (26A + 17A) |
| AC Output Voltage | 380 / 400V (Three Phase) |
| Max Charge Current | 250A |
| Max Efficiency | 97.90% |
| Communication | CAN / RS485 |
| Protection Rating | IP65 |
| Dimensions (W×D×H) | 510 × 630 × 290 mm |
| Weight | 44 kg |
| Warranty | 5 Years |
